We can offer a variety of equipment as well as manufacturing specially designed bit.

Due to the situation of current dependence on imports of natural resources relying on energy demand structure of our country and excessive competition for international securement of resources, the expectation for initiating the development and efficient utilization of natural resources is enhanced. Drilling technology is widely utilized based on geological and geophysical aspects for the development of hot spring in our country possessing a lot of active volcanos, groundwater for drinking and agricutural purposes mainly in overseas countries, underground resources such as mineral resources, e.g. iron ore and coal. Furthermore, a sophistication of drilling technology is highly expected for initiating a mechanism for developing marine resources such as cobalt-enriched crust-deposit, manganese nodule, methane hydrate deposit, etc. We provide the equipment which can be safely and efficiently operated in drilling investigation for mineral exploration.

Product introduction

Application	Series of Model	Size	Model Name
Hot Spring Development	TL	Large Type	TL-2000
	RESORT	Large Type	RESORT-21	RESORT-21HD
	HLL	Large Type	HLL-Special	HLL-Standard	HLL-SUPER
	TSL	Large Type	TSL-1	TSL-HD
Groundwater Development	THS	Small Type	THS-88
	TOM	Medium Type	TOM-3
	TBM	Medium Type	TBM-88	TBM-88LH	TBM-88LH150
	TL	Large Type	TL-2000
	HLL	Large Type	HLL-Special	HLL-Standard	HLL-SUPER
	LFM	Large Type	LFM-400	LFM-700	LFM-1500
	TOP	Large Type	TOP-LS21	TOP-MM	TOP-SS
	TOP	Large Type	TOP-100	TOP-150	TOP-300	TOP-750	TOP-750HR
Mineral Resources Exploration	TOM	Medium Type	TOM-3
	TBM	Medium Type	TBM-88
	TL	Large Type	TL-2000

※ Model with pale colored letters is not utilized in this application.

Development of Hot Spring

Hot spring is utilized not only for tourist facilities, but also for various fields such as the welfare, agriculture, medical, sports facilities, etc. We are engaged in the supply of hot spring water at Bandai Inawashiro Hayama Hot Spring.

Large capacity drill (TL)　Spindle

TL-2000 drill is a large size spindle type drilling machine being designed and manufactured based on the requirement from our customers. This machine is equipped with hydraulic slide base as standard and is a large size machine with high performance. This drill is utilized not only for developing hot spring, but also for mineral exploration. Nominal drilling capacity of this drill for drilling hot srping well is approx. 500 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TL-2000	4.5ｔ	Type （A）	Rotation, forward：20、40、80、150min-1 Rotation, reverse：17min-1	102.0kN	176.5kN	610mm
		Type （B）	Rotation, forward：40、80、160、300min-1 Rotation, reverse：34min-1
		Type （C）	Rotation, forward：60、120、240、450min-1 Rotation, reverse：51min-1

TOA-TONE BORING CO.,LTD.

TL-2000

Large capacity drills (RESORT, HLL)　Drive Head

RESORT-21 drill is a ultra deep hole drilling machine for Hot Spring Development and HLL-Standard, HLL-Special drills are ultra deep hole drilling machine too for geothermal exploration. These drills are drive head type drills and are selected from the requirement of hoisting capacity, rotation speed and rotating torque. RESORT-21 drill is utilized for Hot Spring Development with depth requirement of around 1000 meters. Meanwhile, HLL-Standard and HLL-Special are utilized for the same purpose with around 2000 meters depth.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
RESORT-21	8.6t	Type （A）	Rotation, forward：30、60、120、215min-1 Rotation, reverse：25min-1	98.1kN	323.6kN	750mm
		Type （B）	Rotation, forward：37、75、150、268min-1 Rotation, reverse：31min-1
		Type （C）	Rotation, forward：45、88、177、322min-1 Rotation, reverse：37min-1
HLL-Standard	6.5t	Type （A）	Rotation, forward：20、50、150min-1 Rotation, reverse：12、19min-1	156.9kN	215.7kN	1430mm
		Type （B）	Rotation, forward：40、100、300min-1 Rotation, reverse：24、38min-1
		Type （C）	Rotation, forward：80、200、600min-1 Rotation, reverse：48、76min-1
HLL-Special	8.4t	Rotation, forward：60、120、400min-1 Rotation, reverse：36、72、240min-1		245.2kN	323.6kN	1070mm

TOA-TONE BORING CO.,LTD.

RESORT-21

HLL-Standard

Large capacity drills (RESORT, TSL)　Universal

RESORT-21HD drill is a ultra deep hole drilling machine for Hot Spring Development and TSL-1 andTSL-HD drills are also ultra deep hole drilling machines for geothermal exploration and production .Both drills are universal type drills equipped with drive heads and rotary tables. By moving drive head, both of wireline core drilling and non-core drilling are capable by one machine. These drills are utilized for Hot Spring Development with depth requirement of around 1000 meters and are selectable from the requirement of hoisting capacity, rotation speed and rotating torque.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Rotation Speed		Hoisting Capacity	Stroke Length
Model Name	Machine Weight	Drive Head	Rotary Table	Hoisting Capacity	Stroke Length
RESORT -21HD	10.5t	Rotation, forward： 45、90、180、322min-1	Rotation, forward： 30、58、118、216min-1	8.0t	750mm
RESORT -21HD	10.5t	Rotation, reverse： 37、60、117、236、433min-1		8.0t	750mm
TSL-1	11.0ｔ	Rotation, forward： 60、125、265、42min-1	Rotation, forward： 30、62、132、210min-1	9.0ｔ	750mm
TSL-1	11.0ｔ	Rotation, reverse： 36、75、160、255min-1		9.0ｔ	750mm
TSL-HD	13.0ｔ	Rotation, forward： 47、97、206、327min-1	Rotation, forward： 24、48、103、164min-1	12.0ｔ	750mm
TSL-HD	13.0ｔ	Rotation, reverse： 28、58、124、198min-1		12.0ｔ	750mm

TOA-TONE BORING CO.,LTD.

RESORT-21HD

TSL-1

TSL-HD

Move to top page.

Development of Groundwater

Groundwater is an important resource to be supplied with stable quality for drinking and irrigation purposes., and furthermore, is utilized for the sanitary improvement in developing countries and an attention is paid as drinking water in time of disaster in Japan.

Small capacity drill (THS)　Spindle

THS-88 drill is a small size spindle type drilling machine being designed and manufactured based on the requirement from our customers. This drill is equipped with hydraulic slide base as standard and a high performance drill regarding the operability as important under various working conditions. This drill is utilized not only for drilling water well under ground water development, but also for drilling monitoring well and mineral exploration. Nominal drilling capacity of this drill for water well drilling is approx. 150 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
THS-88	1.05ｔ	Type （A）	Rotation, forward：30、74、138min-1 Rotation, reverse：36min-1	37.3kN	44.1kN	500mm
THS-88	1.05ｔ	Type （B）	Rotation, forward：77、159、297min-1 Rotation, reverse：77mi-1	37.3kN	44.1kN	500mm

TOA-TONE BORING CO.,LTD.

THS-88

Medium capacity drills (TOM, TBM-88)　Spindle

TOM-3 and TBM-88 drills are medium size spindle type drilling machines being designed and manufactured based on the requirement from our customer. These drills are equipped with hydraulic slide base as standard and are medium size high performance drills regarding the operability as important under various working conditions.These drills are utilized not only for drilling water well under ground water development, but also for drilling hot spring well, monitoring well, mineral exploration, cast-in-place pile. Nominal drilling capacity of these drills for water well drilling is with approx. 350 meters for TOM-3 drill and 500 metere for TBM-88 drill respectively.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TOM-3	1.35ｔ	Type （A）	Rotation, forward：30、60、155min-1 Rotation, reverse：30min-1	52.0kN	66.7kN	610mm
		Type （B）	Rotation, forward：120、250、60min-1 Rotation, reverse：120min-1
		Type （C）	Rotation, forward：185、390、920min-1 Rotation, reverse：185min-1
TBM-88	2.25ｔ	Type （A）	Rotation, forward：30、60、100、145min-1 Rotation, reverse：24min-1	68.6kN	78.5kN	500mm
		Type （B）	Rotation, forward：50、100、170、240min-1 Rotation, reverse：40min-1
		Type （C）	Rotation, forward：100、210、350、500min-1 Rotation, reverse：33min-1

TOA-TONE BORING CO.,LTD.

TOM-3

TBM-88

Large capacity drill (TL)　Spindle

TL-2000 drill is a large size spindle type drilling machine being designed and manufactured based on the requirement from our customers. This machine is equipped with hydraulic slide base as standard and is a large size high performance drill regarding the operability as important under various working conditions. This drill is utilized not only for drilling water well under Groundwater Development, but also for drilling hot spring well, monitoring well and mineral exploration. Nominal drilling capacity of this drill for water well drilling is approx. 1200 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TL-2000	4.5ｔ	Type （A）	Rotation, forward：20、40、80、150min-1 Rotation, reverse：17min-1	102.0kN	176.5kN	610mm
		Type （B）	Rotation, forward：40、80、160、300min-1 Rotation, reverse：34min-1
		Type （C）	Rotation, forward：60、120、240、450min-1 Rotation, reverse：51min-1

TOA-TONE BORING CO.,LTD.

TL-2000

Medium capacity drill (TBM-88LH)　Low head drive head

TBM-88LH and TBM-88LH-150 drills are medium size low head and drive head type drilling machines being designed and manufactured based on the requirement from our customers. Since the height of drilling machine during operation is only 1760 mm, safety and efficient drilling operation under low headroom and under road is secured. These drills are utilized not only for drilling water well, but also for drilling hot spring well, monitoring well, cast-in-place pile, etc. Most technical features between TBM-88LH and TBM-88LH-150 drills are identical and it is selectable for spindle diameter of 93 mm or 150 mm.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle			Feed System
Model Name	Machine Weight	Drill Head Rotation Speed		Inner Diameter	Feed Force	Balance Force	Stroke Length
TBM-88LH	3.15ｔ	Type （A）	Rotation, forward：30、60、100、145min-1	93mm	71.6kN	59.8kN	450mm
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward：50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1
TBM-88 LH150	3.4ｔ	Type （A）	Rotation, forward：30、60、100、145min-1	150mm	71.6kN	59.8kN	450mm
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward：50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1

TOA-TONE BORING CO.,LTD.

TBM-88LH

Large capacity drill (HLL)　Large hole diameter drive head

HLL-SUPER is developed for large and deeper hole drilling based on the requirement from our customers. This drill has s high rotating torque and enough feed force and can drill upto 1000 meters with 214 mm hoel diameter. This drill is utilized not only for Groundwater Development, but also for the construction of preventive pile for landslide and geothermal exploration.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
HLL-SUPER	5.5t	Type （A）	Rotation, forward： 15、22、38、58、93、140min-1 Rotation, reverse： 12、19min-1	156.9kN	215.7kN	750mm
HLL-SUPER	5.5t	Type （B）	Rotation, forward： 30、44、76、116、186、280min-1 Rotation, reverse： 24、38min-1	156.9kN	215.7kN	750mm

TOA-TONE BORING CO.,LTD.

HLL-SUPER

Large capacity drill (LFM)　Electrically driven top drive long feed drill

LFM-400, LFM-700 and LFM-1500 are large size electrically driven top drive drills being manufactured based on the requirement from our customers. Compared with hydraulic system, power loss is less and 3 m length hole drilling can be carried out in single continuous operation by DTH hammer method in combination with high rotating torque and long feed stroke. These three models have nominal drilling capacity of 200 m, 400 m and 600 m respectively and are utilized not only for Groundwater Development, but also for steel pipe piling and preventive work for land slide.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed	Feed System
Model Name	Machine Weight	Spindle Rotation Speed	Feed Force	Balance Force	Stroke Length
LFM-400	2.5t	Rotation, forward：18、40min-1	23.3kN	49.0kN	4500mm
LFM-700	5.1t	Rotation, forward：15、26、54、92min-1	41.2kN	94.1kN	4500mm
LFM-1500	6.5t	Rotation, forward：7、14min-1	41.2kN	96.1kN	4500mm

TOA-TONE BORING CO.,LTD.

LFM-700

LFM-400

Large capacity drill (TOP)　Top drive truck mounted

TOP series drills are truck mounted type top drive drills with supply records more than 250 units to Asian, African and South American countires under Official Development Assistance program for the purpose of stable supply for drinking and irrigation water. We can provide the model with the range of drilling depth from 100 m to 750 m (100 m, 150 m, 300 m, 750 m) and these drills have been evaluated with a reputation for good accessbility and mobility in rough terrain.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed	Feed System
Model Name	Machine Weight	Spindle Rotation Speed	Feed Force	Balance Force	Stroke Length
TOP-100	10.0t	Rotation, forward Low ： 0-40min-1　　High ： 0-80min-1	19.6kN	19.6kN	4500mm
TOP-100	10.0t	Rotation, reverse：Same as forward rotation.	19.6kN	19.6kN	4500mm
TOP-150	15.0t	Rotation, forward Low ： 0-45min-1　　High ： 0-90min-1	21.6kN	53.9kN	4500mm
TOP-150	15.0t	Rotation, reverse：Same as forward rotation.	21.6kN	53.9kN	4500mm
TOP-300	22.0t	Rotation, forward Low ： 0-60min-1　　High ： 0-120min-1	31.4kN	68.6kN	7500mm
TOP-300	22.0t	Rotation, reverse：Same as forward rotation.	31.4kN	68.6kN	7500mm
TOP-750	26.0ｔ	Rotation, forward Low ： 0-50min-1　　High ： 0-100min-1	73.5kN	137.2kN	7500mm
TOP-750	26.0ｔ	Rotation, reverse：Same as forward rotation.	73.5kN	137.2kN	7500mm
TOP-750HR	26.0t	Rotation, forward Low ： 0-20min-1　　High ： 0-40min-1	98.0kN	245.0kN	7500mm
TOP-750HR	26.0t	Rotation, reverse：Same as forward rotation.	98.0kN	245.0kN	7500mm

TOA-TONE BORING CO.,LTD.

TOP-300

TOP-750

Move to top page.

Development of Mineral Resources

Japanese technology for refining the metals from the ore is ranked at top level in the world. Development of Mineral Resources including rare metals is a siginificant initiative to aim a sustainable economical development.

Large capacity drill (TL)　Spindle

TOM-3 and TBM-88 drilla are medium size spindle type drilling machines being designed and manufactured based on the requirement from our customer. These drills are equipped with hydraulic slide base as standard and are medium size high performance drills regarding the operability as important under various working conditions.These drills are utilized not only for mineral exploration, but also for drilling hot spring well, monitoring well, cast-in-place pile. Nominal drilling capacity of these drills for mineral exploration is with approx. 350 meters for TOM-3 drill and 500 metere for TBM-88 drill respectively.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TOM-3	1.35ｔ	Type （A）	Rotation, forward：30、60、155min-1 Rotation, reverse：30min-1	52.0kN	66.7kN	610mm
		Type （B）	Rotation, forward：120、250、60min-1 Rotation, reverse：120min-1
		Type （C）	Rotation, forward：185、390、920min-1 Rotation, reverse：185min-1
TBM-88	2.25ｔ	Type （A）	Rotation, forward：30、60、100、145min-1 Rotation, reverse：24min-1	68.6kN	78.5kN	500mm
		Type （B）	Rotation, forward：50、100、170、240min-1 Rotation, reverse：40min-1
		Type （C）	Rotation, forward：100、210、350、500min-1 Rotation, reverse：33min-1

TOA-TONE BORING CO.,LTD.

TOM-3

TBM-88

Large capacity drill (TL)　Spindle

TL-2000 drill is a large size spindle type drilling machine being designed and manufactured based on the requirement from our customers. This machine is equipped with hydraulic slide base as standard and is a large size high performance drill regarding the operability as important under various working conditions. This drill is utilized not only for mineral exploration, but also for drilling hot spring well and monitoring well. Nominal drilling capacity of this drill for water well drilling is approx. 1200 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TL-2000	4.5ｔ	Type （A）	Rotation, forward：20、40、80、150min-1 Rotation, reverse：17min-1	102.0kN	176.5kN	610mm
		Type （B）	Rotation, forward：40、80、160、300min-1 Rotation, reverse：34min-1
		Type （C）	Rotation, forward：60、120、240、450min-1 Rotation, reverse：51min-1

TOA-TONE BORING CO.,LTD.

TL-2000

We can offer a variety of equipment as well as manufacturing specially designed bit.

Development of Hot Spring

Large capacity drill (TL) Spindle

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drills (RESORT, HLL) Drive Head

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drills (RESORT, TSL) Universal

We can offer the equipment with "Only One" features upon customer's request.

Development of Groundwater

Small capacity drill (THS) Spindle

We can offer the equipment with "Only One" features upon customer's request.

Medium capacity drills (TOM, TBM-88) Spindle

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drill (TL) Spindle

We can offer the equipment with "Only One" features upon customer's request.

Medium capacity drill (TBM-88LH) Low head drive head

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drill (HLL) Large hole diameter drive head

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drill (LFM) Electrically driven top drive long feed drill

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drill (TOP) Top drive truck mounted

We can offer the equipment with "Only One" features upon customer's request.

Development of Mineral Resources

Large capacity drill (TL) Spindle

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drill (TL) Spindle

We can offer the equipment with "Only One" features upon customer's request.

Large capacity drill (TL)　Spindle

Large capacity drills (RESORT, HLL)　Drive Head

Large capacity drills (RESORT, TSL)　Universal

Small capacity drill (THS)　Spindle

Medium capacity drills (TOM, TBM-88)　Spindle

Large capacity drill (TL)　Spindle

Medium capacity drill (TBM-88LH)　Low head drive head

Large capacity drill (HLL)　Large hole diameter drive head

Large capacity drill (LFM)　Electrically driven top drive long feed drill

Large capacity drill (TOP)　Top drive truck mounted

Large capacity drill (TL)　Spindle

Large capacity drill (TL)　Spindle
