Foundation is constructed into the underground for the purpose to transmit the weight of structures to the bearing layer. Foundation work is classified, based on the method of transmitting sturucture weight, into ① spread foundation ② pile foundation ③ caisson base ④ diaphragm wall foundation. We can provide the equipment securing the safety and improving operating efficiency for diaphragm walling and cast-in-place piling Construction, meeting the requirement from our customers.

① Spread foundation

In case better bearing layer supporting the structures exists at shallow depth, the weight of structure is directly transmitetd to bearing layer through mat foundation or footing foundation.

② Pile foundation

In case better bearing layer supporting the structures exists at deeper depth, the weight of structure is transmitted to deeply located bearing layer through cast-in-place pile by excavating up to bearing layer or penetrating prestressed concrete pile.

③ Caisson base

The weight of structures is transmitted to bearing layer through box shaped reinforced concrete or steel hollow structure which is installed at specified bearing layer by excavating or sinking it.

④ Diaphragm wall foundation

RC (reinforced concrete) diaphragm wall constructed in the underground with the trencher is just used as foundation body of the structure. It is possible to form simple straight wall, rectangular or polygonal shaped closed-crosssection wall.

Product introduction

Application	Series of Model	Size	Model Name
Diaphragm Wall Construction	TMX	Large Type	MPD-TMX
	BMX	Large Type	BMX-120	BMX-200	BMX-240
	EMX	Large Type	EMX-150	EMX-240	EMX-320
	CMX	Large Type	CMX-SE
	SMX	Large Type	SMX
	TMW	Large Type	TMW-520	TMW-600
Cast-in-Place Pile Construction	TBM	Medium Type	TBM-88	TBM-88LH	TBM-88LH150
	JET	Medium Type	JET-18
	TBH	Medium Type	TBH-8	TBH-15
	MPD-TBH	Large Type	MPD-25	MPD-45

※ Model with pale colored letters is not utilized in this application.

Diaphragm Wall Construction

Diaphragm wall construction is one of key technologies of civil works and is to construct a continuous wall as foundation or retaining wall when a large scale structure is constructed in the underground.

Rotary multi-horizontal cutter diaphragm wall trencher

Rotary multi-horizontal cutter diaphragm wall trencher is a representative machine utilized for the construction of diaphragm wall and a requirement for strengthening its performance and capability is expected for future large scale projects such as underground railway and highway.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Wall Thickness	Wall Thickness	Excavating Depth (approx.)	Drum Cutter Rotation Speed	Rotating Torque
MPD-TMX	7.0t	650- 1000mm	2400mm 3200mm	70m	Low ：0-16min-1 High ：0-32min-1	Low ：63.7kN・m High ：31.8kN・m
SMX	7.5t	650- 1000mm	2400mm	70m	Low ：0-16min-1 High ：0-32min-1	Low ：63.7kN・m High ：31.8kN・m
BMX-120	32.0t （Wall Thickness： at 1200 mm）	650- 1200mm	3200mm	40m Suspended by 80 ton crane as standard and equipped with simplified non-joint device 50-70m Mounted on low head MRD base machine 70m Suspended by 100 ton crane as standard and equipped with simplified non-joint device 150m Suspended by 100 ton crane as standard and equipped with pipe joint or hose drum system	0-20min-1	78.5kN・m
BMX-200	36.0t （Wall Thickness： at 2000 mm）	800- 2000mm	3200mm		0-18min-1	94.1kN・m
BMX-250	32.0t （Wall Thickness： at 2400 mm）	1000- 2400mm	2400mm		0-28min-1	56.4kN・m
CMX-SE	18.0t （Wall Thickness： at 1500 mm）	800- 1500mm (OP:1500- 2400mm)	2400mm 2800mm 3200mm	70m Low Head MRD Type （OP：100m）	Low ：0-22min-1 High ：0-44min-1	Low ：80.0kN・m High ：40.0kN・m
EMX-150	33.0t （Wall Thickness： at 1500 mm）	800- 1500mm (OP:1500- 2000mm)	3200mm	150m	9.1min-1	68.6kN・m
EMX-240	35.0t （Wall Thickness： at 2000 mm）	1200- 2400mm (OP:1000- 1200mm)	3200mm	150m	12.4min-1	50.0kN・m
EMX-320	56.0t	2880mm	3200mm	150m	7.8min-1	90.0kN・m

TOA-TONE BORING CO.,LTD.

MPD-TMX

BMX-200

EMX-240

SMX

CMX-SE

Multi-auger type diaphragm walling machine

Multi-auger type diaphragm walling machine is the equipment to form a rectangular soil-mixing column wall by mixing and kneading the soil and cement slurry as excavating with multi-augers. Side wall cutter can remove uncut section remained by auger head excavation and construct a rectangular wall with flat surface. This trencher is utilized based on designing and site conditions due to its better operating performance for shallow retaining wall construction.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name

Cutter
Weight

Wall
Thickness

Wall
Width

Excavating
Depth
(approx.)

Drum Cutter
Rotation Speed

Rotating Torque

TMW-520

1.6t

550-
650mm

1590-
1690mm

60m

≪Frequency：50HZ≫

Low	17.5min-1
High	35.0min-1

≪Frequency：60HZ≫

Low	21.0min-1
High	42.0min-1

≪Frequency：50HZ≫

Low	70.6kN・m
High	35.0kN・m

≪Frequency：60HZ≫

Low	58.3kN・m
High	29.1kN・m

TMW-600

3.0t

650-
850mm

1850-
2050mm

60m

≪Frequency：50HZ≫

Low	15.0min-1
High	30.0min-1

≪Frequency：60HZ≫

Low	95.5min-1
High	47.8min-1

≪Frequency：50HZ≫

Low	18.0kN・m
High	36.0kN・m

≪Frequency：60HZ≫

Low	79.4kN・m
High	39.7kN・m

TOA-TONE BORING CO.,LTD.

TMW-520

Move to top page.

Cast-in-Place Pile Construction

Cast-in-place pile construction is to drill the ground, install reinforced steel cage in excavated hole, then place ready mixted concrete in order to construct reinforced concrete pile at the site.

Cast-in-Place Piling Machine

For cast-in-place pile construction, various construction methods are selected based on drilling method, pile diameter, pile length, etc. Especially for the work in urban area, the safety secured and smooth work at resctricted space is essential and it is very important to select the proper working method and machine in consideration of environmental affection such as the noise or vibration.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System			Structure
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length	Structure
TBM-88	2.25t	Type （A）	Rotation, forward： 30、60、100、145min-1	68.6kN	78.5kN	500mm	Spindle Type
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward： 50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1
		Type （C）	Rotation, forward： 100、210、350、500min-1
		Type （C）	Rotation, reverse：33min-1
TBM-88LH	3.15t	Type （A）	Rotation, forward： 30、60、100、145min-1	71.6kN	59.8kN	450mm	Low Head Drive Head Type
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward： 50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1
TBM-88 LH150	3.4t	Type （A）	Rotation, forward： 30、60、100、145min-1	71.6kN	59.8kN	450mm	Low Head Drive Head Type
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward： 50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1
JET-18	4.0t	Low ：7.5min-1 High ：15min-1		98.1kN	98.1kN	1100mm	Reverse Circulation Low Head Top Drive Type
TBH-8	7.0t	Low ：7.5min-1 High ：20min-1		98.1kN	98.1kN	1750mm	Reverse Circulation Top Drive Type
TBH-15	10.0t	Low ：7.5min-1 High ：20min-1		147.1kN	147.1kN	3200mm	Reverse Circulation Top Drive Type
MPD-25	13.0t	Low ：0-7min-1 Middle ：0-14min-1 High ：0-28min-1		98.0kN	147.0kN	1220- 2320mm	Reverse Circulation Top Drive Type
MPD-45	13.0t	Low ：0-10min-1 High ：0-20min-1		98.0kN	147.0kN	1750- 3500mm	Reverse Circulation Top Drive Type

TOA-TONE BORING CO.,LTD.

TBM-88

TBM-88LH

JET-18

TBH-8

MPD-25

MPD-45
