Uniform drilling fluid can be made by jet stream much quicker
Mud mixer is an agitator that mixes bentonite or alternative substances with water to produce the circulating fluid (mud water) for drilling operations.
It can be also used for mixing cement milk, various chemicals, and other injection materials.
MCK Series Mud Mixer employs a Turbo-jet-stream system, which offers enhanced safety features compared to the conventional propeller-type mixers.
It can be also used for mixing cement milk, various chemicals, and other injection materials.
MCK Series Mud Mixer employs a Turbo-jet-stream system, which offers enhanced safety features compared to the conventional propeller-type mixers.
Product introduction
| Model | MCK250 | MCK500 | |
|---|---|---|---|
| Type | Single tank（Turbo-jet-stream） | ||
| Capacity | Tank（L） | 250 | 690 |
| Mixing（L） | 200 | 500 | |
| Rotation speed（rpm） | 1,440 x 1,730 | 1,440 x 1,730 | |
| Required power（kW） | 7.5 | 7.5 x 2台 | |
| Weight（kg） | 425 | 930 | |
MCK-500（Front）
MCK-500（Rear）
