We provide enough lineup of equipment suitable for the applications.

In construction works, an investigation is carried out to comprehend the characteristics and strength of the ground preliminarily at each stage of planning, designing and constructing.
Drilling into the ground which is not visible directly is a popular investigation method. The target required such investigation in construction works widely covers such as buildings, railway, tunnel, dam, bridge foundation, airport, harbor, etc., and such invetigation is an indispensable measure to construct the structures. In recentl years, the demand of investigation by drilling as Scientific Investigations such as geological and active fault investigation relating to earthquake prediction increases. We provide the equipment which can be safely and efficiently operated in drilling investigation for the field of construction works and Scientific Investigation.

Product introduction

Application	Series of Model	Size	Model Name
Investigation for Construction Work	TS	Small Type	TS-100
	TDC	Small Type	TDC-1G
	TEC	Small Type	TEC-1
	THC	Small Type	THC-1
	TOP	Large Type	TOP-LS21	TOP-MM	TOP-SS
	TOP	Large Type	TOP-100	TOP-150	TOP-300	TOP-750	TOP-750HR
Scientific Investigation	TBM	Medium Type	TBM-88	TBM-88LH	TBM-88LH150
	TL	Large Type	TL-2000
	TSL	Large Type	TSL-1	TSL-HD

※ Model with pale colored letters is not utilized in this application.

Small capacity drills (TS, TDC, TEC, THC)　Spindle

TS-100, TDC-1G, TEC-1 and THC-1 drills are compact and light weight drilling machines being designed and manufactured based on the requirement from our customers. Compact and light weight drills are easy for transportation, assembling and disassembling, and enables to be operated at small restricted space. Due to equipping hydraulic system, operational efficiency and safety are well considered. These drills are utilized not only for an investigation for construction worls, but also for drilling grout hole, blast hole and domestic water well.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed	Feed System
Model Name	Machine Weight	Spindle Rotation Speed	Feed Force	Balance Force	Stroke Length
TS-100	290kg	Type（A）：65、135、255min-1	13.7kN	19.6kN	400mm
TS-100	290kg	Type（B）：120、250、480min-1	13.7kN	19.6kN	400mm
TDC-1G	430kg	Type（A）：55、110、230min-1	11.8kN	17.7kN	450mm
TDC-1G	430kg	Type（B）：135、270、560min-1	11.8kN	17.7kN	450mm
TEC-1	535kg	Type（A）：67、139、265min-1	20.2kN	27.0kN	500mm
TEC-1	535kg	Type（B）：128、265、505min-1	20.2kN	27.0kN	500mm
THC-1	700kg	Type（A）：55、125、245、550min-1	17.7kN	19.6kN	500mm
THC-1	700kg	Type（B）：30、70、130、300min-1	17.7kN	19.6kN	500mm

Factory Option

Hydraulic slide base and hydraulic chuck of TS-100 drill
Hydraulic chuck and cone pulley with cover of TDC-1G drill
Hydraulic slide base of TEC-1 drill
Hydraulic chuck, spindle safety cover and cone pulley of THC-1 drill

TS-100

TEC-1

TOA-TONE BORING CO.,LTD.

TS-100

TEC-1

TDC-1G

THC-1

Move to top page.

Medium capacity drill (TBM-88)　Spindle

TBM-88 drill is a large size spindle type drilling machine being designed and manufactured based on the requirement from our customer. This drill is equipped with hydraulic slide base as standard and is a medium size high performance drill regarding the operability as important under various working conditions.This drill is utilized not only for a Scientific Investigation such as monitoring well, but also for drilling hot spring well, water well, mineral exploration, cast-in-place pile, etc. Nominal drilling capacity of this drill for drilling monitoring well is with approx. 500 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TBM-88	2.25ｔ	Type （A）	Rotation, forward：30、60、100、145min-1	68.6kN	78.5kN	500mm
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward：50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1
		Type （C）	Rotation, forward：100、210、350、500min-1
		Type （C）	Rotation, reverse：33min-1

Factory Option

Hydraulic chuck, out rigger, spindle safety cover and platform of TBM-88 drill

TOA-TONE BORING CO.,LTD.

TBM-88

Move to top page.

Medium capacity drill (TBM-88LH)　Low head drive head

TBM-88LH and TBM-88LH-150 drills are medium size low head and drive head type drilling machines being designed and manufactured based on the requirement from our customers. Since the height of drilling machine during operation is only 1760 mm, safety and efficient drilling operation under low headroom and under road is secured. These drills are utilized not only for a scientific ivnestigation such as monitoring well, but also for drilling hot spring well, water well, mineral exploration, cast-in-place pile, etc. Most technical features between TBM-88LH and TBM-88LH-150 drills are identical and it is selectable for spindle diameter of 93 mm or 150 mm.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle			Feed System
Model Name	Machine Weight	Drill Head Rotation Speed		Inner Diameter	Feed Force	Balance Force	Stroke Length
TBM-88LH	3.15ｔ	Type （A）	Rotation, forward：30、60、100、145min-1	93mm	71.6kN	59.8kN	450mm
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward：50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1
TBM-88 LH150	3.4ｔ	Type （A）	Rotation, forward：30、60、100、145min-1	150mm	71.6kN	59.8kN	450mm
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward：50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1

Factory Option

Hydraulic chuck, out rigger, platform

TOA-TONE BORING CO.,LTD.

TBM-88LH

Move to top page.

Large capacity drill (TL)　Spindle

TL-2000 drill is a large size spindle type drilling machine being designed and manufactured based on the requirement from our customers. This machine is equipped with hydraulic slide base as standard and is a large size machine with high performance regarding the operability as important under various working conditions. This drill is utilized not only for a scientific ivnestigation such as monitoring well, but also for drilling hot spring well, water well, mineral exploration, etc. Nominal drilling capacity of this drill for drilling monitoring well is approx. 1200 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TL-2000	4.5ｔ	Type （A）	Rotation, forward：20、40、80、150min-1	102.0kN	176.5kN	610mm
		Type （A）	Rotation, reverse：17min-1
		Type （B）	Rotation, forward：40、80、160、300min-1
		Type （B）	Rotation, reverse：34min-1
		Type （C）	Rotation, forward：60、120、240、450min-1
		Type （C）	Rotation, reverse：51min-1

Factory Option

Hydraulic chuck, hydraulic brake, spindle with inner diameter of 160mm of TL-2000 drill

TOA-TONE BORING CO.,LTD.

TL-2000

Move to top page.

Large capacity drill (TSL)　Universal

TSL-HD drill has been developed as ultra deep hole drilling machine for the geothermal exploration and production wells. This drill is a universal type drill equipped with both of drive head and rotary table. By moving drive head, both of wireline core drilling and non-core drilling are carried out by one machine. This drill is utilized too for drilling hot spring well with the depth requirement of 1000 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Rotation Speed		Hoisting Capacity	Stroke Length
Model Name	Machine Weight	Drive Head	Rotary Table	Hoisting Capacity	Stroke Length
TSL-1	11.0ｔ	Rotation, forward： 60、125、265、420min-1	Rotation, forward： 30、62、132、210min-1	9.0ｔ	750mm
TSL-1	11.0ｔ	Rotation, reverse： 36、75、160、255min-1		9.0ｔ	750mm
TSL-HD	13.0ｔ	Rotation, forward： 47、97、206、327min-1	Rotation, forward： 24、48、103、164min-1	12.0ｔ	750mm
TSL-HD	13.0ｔ	Rotation, reverse： 28、58、124、198min-1		12.0ｔ	750mm

TOA-TONE BORING CO.,LTD.

TSL-HD

Move to top page.

Large capacity drill (TOP)　Horizontal drilling

TOP-LS21, TOP-MM and TOP-SS drills are specially designed for horizontal drilling and enable horizontal drilling in fractured formation. The function of drill has dual tube system to rotate outer casing and inner rod simultaneously. Drilling proceeds as inner bit drills inside outer casing and outer bit drills around outer casing by protecting inner rod from the jamming or formation collapse for smooth penetration of inner rod. Model is selectable meeting the depth to be drilled, depending on rotation torque, feed force, balance force, etc.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle		Feed System
Model Name	Machine Weight	Max. Torque	Rotation Speed	Feed Force	Pull Force	Stroke Length
TOP-LS21	5.5ｔ	Low Speed：19.6 kN・m	Low Speed：7-29 min-1	117.7kN	117.7kN	1800 or 1800×2mm
		2rd：9.5 kN・m	2rd：14-60 min-1
		3rd：4.8 kN・m	3rd：29-118 min-1
		High Speed：2.3 kN・m	High Speed：58-244 min-1
TOP-MM	1.3ｔ	Low Speed：5.9 kN・m	Low Speed：0-30 min-1	58.8kN	58.8kN	1400mm
TOP-MM	1.3ｔ	High Speed：2.9 kN・m	High Speed：0-60 min-1	58.8kN	58.8kN	1400mm
TOP-SS	0.5t	Low Speed：4.9 kN・m	Low Speed：0-30 min-1	29.4kN	29.4kN	1400mm
TOP-SS	0.5t	High Speed：2.5 kN・m	High Speed：0-60 min-1	29.4kN	29.4kN	1400mm
