We fulfill the requirement from our customers of various fields.

We mainly manufacture and sell drilling machines and diaphragm wall trenchers for domesctic and overseas, and create new technologies with "Only One" feature to meet the requirement from our customers of various fields. Among them, we introduce the decontamination machine of farmland as a result from the incidence of the Great East japan Earthquake, and an aseismic reinforcing anchor for existing harbor quay.

Product introduction

Application Series
of Model
Size Model Name
Pavement TTSD Small Type TTSD-01C
TTS Medium Type TTS-1
EP Small Type EP-10LH
Medium Type EP-26,EP-26N
Radioactive decontamination RSC Large Type RSC-200
Aseismic reinforcement HDS Large Type Ein Band Drill

※ Model with pale colored letters is not utilized in this application.

Pavement

In order to maintain and repair the road efficiently, it is essential to make a structural evaluation of existed pavement properly. Drilling machine which can investigate the paved structure easily due to the spread of FWD test investgating bearing capacity or residual Ta of the pavement with non-destructive measure is required.

Small capacity drill (TTSD) Portable

TTSD-01C drill is a portable survey drill being designed and manufactured based on the requirement from our customers. This drill is powered by 100 V generator and mounted on a carrier to enable smooth movement during transportation or on the road. By the use of dual tube type core barrel, the sample with nearly original thickness of asphalt mixture, granulated crushed-stone roadbed or subsoil can be collected without the disturbance by circulation fluid.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name
Gross
Weight
Required Power Source Sampling
Depth
Drilling
Diameter
Sample
Diameter
TTSD-01C 0.13t 100V 100cm 86mm 70mm

Features

  • Knockdown type easy for transportation
  • Easy recovery work because of 86 mm drilling diameter
  • Capable of collecting sample without moistening
  • Use of M2 type standard diamond bit and J1 type diamond bit for hard layer such as slag type roadbed

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
TTSD-01C
TOA-TONE BORING CO.,LTD.
TTSD-01C
TOA-TONE BORING CO.,LTD.
TTSD-01C

Medium Type (Soil Auger Drill "TTS-1") truck mounted

Soil Auger Drill "TTS-1" is truck mounted type pavement investigation drill designed and manufactured based on the requirement of our customer. This drill can drill upto 1.05 m depth with large hole diameter (250mm) and has feed force with max. 35.2 kN enabling to drill the pavement being composed of hard layer such as slag subbase.

We can offer the equipment with "Only One" features upon customer's request.

Model Gross Weight Vehicle Weight Drill Unit Weight Drilling Depth Drilling Diameter
TTS-1 4.6t 2.3t 2.3t 105cm 250mm

Features

  • Anyone with ordinary driving license can drive the truck with 3 ton low flat bed of drill
  • Easy operation
  • Smooth lifting/lowering and sliding actions of drill unit by means of hydraulic cylinder
  • Standard equipment of flashing light and LED sign of "WORK IN PROGRESS"
  • Standard equipment of lightings for night work
  • To be provided with a tamper for backfilling materials (optional)
  • Enable to drill with hole diameter up to 320mm (optional)

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
TTS-1
TOA-TONE BORING CO.,LTD.
TTS-1
TOA-TONE BORING CO.,LTD.
TTS-1

Small capacity drill (EP-10LH) Low head rotary and vibration

EP-10LH Drill is a compact low-head drill with both of rotation and vibration mechanism being designed and manufactured based on the requirement from our customers. Drilling efficiency is remarkably improved by means of an innovative mechanism for drilling by giving both of rotation and vibration to drill bit and this drill becomes a popular model being friendly to neighboring environment because of creating low noise.
This drill is capable of high speed sampling without use of circulation fluid for about 1 meter depth and also capable of dual pipe sampling method in case the sampling of soft ground or deeper sampling is required. The height of drill during operation is 2.3 meters to meet low headroom requirement and the operation under various working conditions is possible.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name
Gross
Weight
Sample
Diameter
Drilling
Depth
Drill Head Feed System
Rotation
Speed
Rotating
Torque
Feed
Force
Balance
Force
Stroke
Length
EP-10LH 1.2t 66-
138mm
10m 0-20min-1 0.882kN/m 19.6kN 34.3kN 1350mm

Features

  • Active use for sampling work on the road as well as in the restricted space
  • Low noise and vibration being friendly to neighboring environment by means of unique vibration mechanism
  • Easy operation without technical skill requirement
  • High speed sampling without use of circulation fluid
  • Foldable leader during transportation and mobilization
  • Availability of vehicle mounted type drill posessing EP mechanism
  • Use of hydraulic oil of biodegradable vegitable oil being friendly to the environment

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
EP-10LH
TOA-TONE BORING CO.,LTD.
EP-10LH
TOA-TONE BORING CO.,LTD.
EP-10LH

Radioactive decontamination

Under the incidence of Fukushima nuclear power plant accident by the Great East Japan Earthquake, a proper decontamination based on radiological dosage is carried out according to decontamination action plan in the area designated as Special Area for Decontamination. Decontamination methods with rationally available technologies are taken .

Large capacity drill (RSC) Surface scraping of farmland

Based on Act on special measure concerning the countermeasure for radioactive contamination and the basic policy made by the cabinet decision followed by this Act in 2011, the initiative for decontamination under the responsibility of the government has been taken. Long-term proper measure is planned in order to aim the additional radiation dose less than 1mSv/year after 2014.
RSC-200 is the machine to scrape surface soil with 5 - 10 cm thicknee at farmland and to load the contaminated soil into a tonpack located at the rear of machine using belt conveyor. This machine has been used for decontamination work of farmland in Iidate Village designated as Special Area for Decontamination since 2012.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name
Gross
Weight
Cutter Rotation
Drive Mechanism
Chain
Conveyer
Width
Belt
Conveyer
Width
Tilting Angle
Rotation
Speed
Rotating
Torque
RSC-200 5.5t 242min-1
(at 40 L/min.)
0.72kN/m 754mm 600mm
Up and Down:-200~+500mm
Left and Right:±4.5°

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
RSC-200
TOA-TONE BORING CO.,LTD.
RSC-200
TOA-TONE BORING CO.,LTD.
RSC-200

Aseismic reinforcement

Japan is a country subject to frequent earthquakes and the urgent provision of construction for aseismic reinforced wharf in order to secure the transportation of relief supplies and business activities at the incidence of Tokai, Tonankai and Nankai Earthquakes is required.

Large size drill (Ein Band Drill) Rotary Percussion

Based on "Program for Urgent Wharf Aseismic Reinforcement and Improvement" settled by Ministry of Land, Infrastructure, Transport and Tourism on March, 2006, only approx. 66% of wharves have been improved by 2010. Furthermore, after the incidence of the Great East Japan Earthquake in 2011, deep-draft ships such as ferry and roll-on/roll-off ship have been active for the tranportion of urgent relief supplies and the necessity of aseismic reinforcement of wharves to accommodate such ships is re-recognized.
"Ein Band Drill" is a hydraulic rotary percussion drill with enough feed force to install a long anchor, and with powerful percussive energy to penetrate through caisson base and embedded stone at base mouond behind the caisson for harbor aseismic reinforcement anchoring.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name
Machine
Weight
Cutter
Torque
Pull
Force
Dimensions during Transportation
Height Width Length
Ein Band Drill 13.0t 24kN/m 180KN 1910mm 2380mm 8250mm

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
Ein Band Drill
TOA-TONE BORING CO.,LTD.
Ein Band Drill
TOA-TONE BORING CO.,LTD.
Ein Band Drill
