We provide a lineup of low noise drills enabling the sampling without circulation fluid.

The contamination of soil and ground water is placed as one of seven environmental pollutions which is harmful to the human health or the ecosystem by the toxic substances such as heavy metals created under processing in the factory or refinery, VOC (Volatile Organic Compound) being used for cleaning the semiconductor or metal based products and alkyl phosophate contained in the pesticide. In recent years, by the enforcement of Soil Contamination Countermeasures Act in 2003 and the amendment of this Act in 2010, the demand of Environmental Investigation for Soil and ground water for real estate such as residential lot, farm land and used place as factory is increased. We can provide the equipment to be operated safely and efficiently for Environmental Investigation for Soil and ground water in consideration of neighboring environment.

Product introduction

Application Series
of Model		 Size Model Name
Environmental Investigation for Soil EP Small Type EP-10LH EP-15LH
Medium Type EP-26 EP-26N
SP Large Type SP-8000 SP-50
Environmental Investigation for Groundwater EP Small Type EP-10LH EP-15LH
Medium Type EP-26 EP-26N
SP Large Type SP-8000 SP-50

※ Model with pale colored letters is not utilized in this application.

TOA-TONE BORING CO.,LTD.
TOA-TONE BORING CO.,LTD.

Environmental Investigation for Soil

Environmental investigation is to collect the sample by drilling into invisible ground and is conducted by evaluating the diffused range of contaminated formation, identification of type of toxic substance and proper method of decontamination.

Small capacity drill (EP-10LH)　Low head rotary and vibration

EP-10LH is a small size low head type vibratory rotary drill being designed and manufactured based on the requirement from our customers. This drill has an innovative drilling system giving the rotation and vibration to drill bit and is a popular model offering remarkable improvement of drilling efficiency compared with hydraulic percussion drill as well as considering the neighboring environment due to its low noise creation. This drill is capable of high speed sampling to collect undisturbed samples without the use of circulation fluid, furthermore, can conduct the sampling and drilling of monitoring well at same time by means of dual tube method. EP-10LH has the lowest height of 2.3 m during operation and is suitable for indoor operation.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
EP-10LH 1.2ｔ

0-20min-1

0.882kN/m
19.6kN 34.3kN 1350mm

Features

  • Active in the sampling at restriced small space as well as indoor space
  • Low noise and vibration considering neighboring environment by means of unique vibration mechanism
  • Actualization of simple operability without requirement of special skill
  • High speed sampling without use of circulation fluid
  • Foldable leader during transportation and mobilization
  • Use of hydraulic oil of biodegradable vegitable oil being friendly to the environment

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
EP-10LH
TOA-TONE BORING CO.,LTD.
EP-10LH

Small capacity drill (EP-15LH)　Low headrotary and vibratory

Based on the requirement from our customer, "EP-15LH" is designed and manufactured as a next generation model of "EP-10LH". "EP-15LH" is a compact and low head vibratory-rotary drill which can drill by giving rotation and vibration to drill bit as well as "EP-10LH ". "EP-15LH" drill actualizes the reduction of drilling time by increasing its vibration force more than 3 times compared with "EP-10LH". Furthermore, by installing optional water swivel, this drill enables to have wider drilling applications such as water well, underground geothermal hole, etc.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
EP-15LH 2.4ｔ

Low：0-30min-1
High：0-70min-1

Low：1.47kN・m
High：0.74kN・m

20.0kN 49.0kN 1400mm

Features

  • Active in the sampling at restriced small space as well as indoor space
  • Workable with doors with ceiling height of 2.3 m by removing head sheave.
  • Low noise and vibration considering neighboring environment by means of unique vibration mechanism
  • Actualization of simple operability without requirement of special skill
  • High speed sampling without use of circulation fluid
  • Foldable leader during transportation and mobilization
  • Use of hydraulic oil of biodegradable vegitable oil being friendly to the environment

Factory Option

  • Water swivel

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
EP-15LH
TOA-TONE BORING CO.,LTD.
EP-15LH

Medium capacity drill (EP-26)　Rotary and vibration

EP-26 is a medium size low head type vibratory rotary drill being designed and manufactured based on the requirement from our customers. This drill has an innovative drilling system giving the rotation and vibration to drill bit and is a popular model offering remarkable improvement of drilling efficiency compared with hydraulic percussion drill as well as considering the neighboring environment due to its low noise creation. This drill is capable of high speed sampling to collect undisturbed samples without the use of circulation fluid, furthermore, can conduct the sampling and drilling of monitoring well at same time by means of dual tube method.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
EP-26 2.65t

Low：0-30min-1
High：0-60min-1

Low：3.4kN・m
High：1.7kN・m

20.6kN 97.8kN 1400mm

Features

  • Low noise and vibration considering neighboring environment by means of unique vibration mechanism
  • Actualization of simple operability without requirement of special skill
  • High speed sampling without use of circulation fluid
  • Foldable leader during transportation and mobilization
  • Use of hydraulic oil of biodegradable vegitable oil being friendly to the environment

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
EP-26
TOA-TONE BORING CO.,LTD.
EP-26

Medium capacity drill (EP-26N)　Rotary and vibration

EP-26N drill is a medium type vibration and rotary drill by giving minor changes on existing EP-26 drill based on customer's request. Even though mechanical features of EP-26N drill are same as those of EP-26 drill, EP-26N drill has better noise-reduction by changing the structure aiming at higher durability and improved maintenance procedure.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
EP-26N 2.65t

Low：0-30min-1
High：0-60min-1

Low：3.4kN・m
High：1.7kN・m

20.6kN 97.8kN 1400mm

Features

　Details of minor changes are as follows:

  • Higher durability of spindle by enlarging its minimum OD from 35 mm to 53mm to withstand deviated drilling.
  • Increase of strength of swivel head by changing gear case material from aluminium to steel.
  • Improved maintenance procedure by means of simplified spindle structure.
  • Better noise-reduction.
  • Improved workability by increasing length of handling rod from 1.0 m to 1.5 m. (optional)

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
EP-26N

Large capacity drill (SP)　Rotary and vibration

SP-50 has an innovative drilling system giving the rotation and vibration to drill bit and is a popular model offering remarkable improvement of drilling efficiency compared with hydraulic percussion drill as well as considering the neighboring environment due to its low noise creation. This drill is capable of high speed sampling to collect undisturbed samples without the use of circulation fluid like "EP" series drills. SP-50 has a bigger drilling capacity than that of "EP" series drills and is utilized for drilling heat exchange hole for Underground Thermal Energy utilization.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
SP-50 4.45t

Low：0-36min-1
High：0-62min-1

Low：4.2kN・m
High：2.1kN・m

20.0kN 93.2kN 1600mm

Features

  • Drilling capability for sand, gravel and boulder layer by means of unique vibration mechanism
  • Unique low noise and vibration mechanism being friednly to neighboring environment
  • High speed sampling without use of circulation fluid
  • High drilling performance despite its compact design
  • Foldable leadler during transportation and mobilization
  • Easy transportation with 4 ton truck by removing auxiliary power unit

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
SP-50
TOA-TONE BORING CO.,LTD.
SP-50

Environmental Investigation for Groundwater

Environmental investigation for ground water contamination is to identify type of toxic substance being diffused by ground water flow which is permeated deeply in the ground without being caught in the soil, or evaluate the diffused range of ground water by constructing monitoring well.

Medium capacity drill (EP-26)　Rotary and vibration

EP-26 is a medium size low head type vibratory rotary drill being designed and manufactured based on the requirement from our customers. This drill has an innovative drilling system giving the rotation and vibration to drill bit and is a popular model offering remarkable improvement of drilling efficiency compared with hydraulic percussion drill as well as considering the neighboring environment due to its low noise creation. This drill is capable of high speed sampling to collect undisturbed samples without the use of circulation fluid, furthermore, can conduct the sampling and drilling of monitoring well at same time by means of dual tube method.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
EP-26 2.65t

Low：0-30min-1
High：0-60min-1

Low：3.2kN・m
High：1.6kN・m

19.6kN 93.2kN 1400mm

Features

  • Low noise and vibration considering neighboring environment by means of unique vibration mechanism
  • Actualization of simple operability without requirement of special skill
  • High speed sampling without use of circulation fluid
  • Foldable leader during transportation and mobilization
  • Use of hydraulic oil of biodegradable vegitable oil being friendly to the environment

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
EP-26
TOA-TONE BORING CO.,LTD.
EP-26

Medium capacity drill (EP-26N)　Rotary and vibration

EP-26N drill is a medium type vibration and rotary drill by giving minor changes on existing EP-26 drill based on customer's request. Even though mechanical features of EP-26N drill are same as those of EP-26 drill, EP-26N drill has better noise-reduction by changing the structure aiming at higher durability and improved maintenance procedure.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
EP-26N 2.65t

Low：0-30min-1
High：0-60min-1

Low：3.4kN・m
High：1.7kN・m

20.6kN 97.8kN 1400mm

Features

　Details of minor changes are as follows:

  • Higher durability of spindle by enlarging its minimum OD from 35 mm to 53mm to withstand deviated drilling.
  • Increase of strength of swivel head by changing gear case material from aluminium to steel.
  • Improved maintenance procedure by means of simplified spindle structure.
  • Better noise-reduction.
  • Improved workability by increasing length of handling rod from 1.0 m to 1.5 m. (optional)

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
EP-26N

Large capacity drill (SP)　Rotary and vibration

SP-8000 and SP-50 have innovative drilling system giving the rotation and vibration to drill bit and are popular models offering remarkable improvement of drilling efficiency compared with hydraulic percussion drill as well as considering the neighboring environment due to its low noise creation. These drills are capable of high speed sampling to collect undisturbed samples without the use of circulation fluid like "EP" series drills. "SP" series drills have bigger drilling capacity than those of "EP" series drills and are utilized for drilling heat exchange hole for Underground Thermal Energy utilization.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
SP-8000 5.5t
（7.3t:O.P）

Low
：0-27min-1
：0-33min-1（O.P）

Low：5.4kN･m

46.0kN 98.0kN 1800mm
3000mm
（O.P）

High
：0-54.2min-1
：0-105min-1
（At without use of vibration）

High：2.7kN･m

SP-50 4.45t

Low：0-36min-1
High：0-62min-1

Low：4.2kN･m
High：2.1kN･m

20.0kN 93.2kN 1600mm

Features

  • Drilling capability for sand, gravel and boulder layer by means of unique vibration mechanism
  • Unique low noise and vibration mechanism being friednly to neighboring environment
  • High speed sampling without use of circulation fluid
  • High drilling performance despite its compact design
  • Foldable leadler during transportation and mobilization
  • Optional tilting system of drill head (for SP-8000 drill)
  • Optional longer mast to use 2.0 m long drill rod (for SP-8000 drill)
  • Easy transportation with 4 ton truck by removing auxiliary power unit (for SP-50 drill)

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
SP-8000
TOA-TONE BORING CO.,LTD.
SP-8000
TOA-TONE BORING CO.,LTD.
SP-8000
TOA-TONE BORING CO.,LTD.
SP-50
TOA-TONE BORING CO.,LTD.
SP-50
